TRANSPORTATION INTERCHANGE MKAD ON THE INTERSECTION OF OSTASHKOVSKOE SHOSSE

Transportation interchange is located within North-East area of Severo-Medvedkovo District of Moscow about 90-91 km from MKAD.
Type of works: new construction and reconstruction.
The Project includes reconstruction of Ostashkovskoe Shosse Transportation Interchange and MKAD with exits and pedestrian crossings.
The following measures should be completed:MKAD transportation flow separation together with exits flows from adjacent roadways;
Spots of left turn transportation flows intersections elimination within cloverleaf types transport junctions;
Arrangement of two extra left turn exits.

CLIENT

Department of Roads and Bridges Construction, Moscow

DESIGN STAGE

2019 — 2020

CONSTRUCTIONN STAGE

2020 — 2022

TRANSPORT JUNCTION INCLUDES

2 side roads along МKAD;
10 exits;
4 viaducts;
1 pedestrian crossing.

SCOPE OF WORK

Stage: DD, WD
General Design.

TECHNICAL FEATURES

SIDE ROAD P1one way , two way and three way road of – 1,021. 8 m,
flyover – 119.5 m;
material – RC ;
road schema 30.0+48.0+30.0 m;
total width – 15.41 m;
carriageway width – 13.25 m.

SIDE ROAD P2one way , two way and three way road of – 641,05 m,
flyover – 119.4 m;
material – RC;
road schema 30.0+48.0+30.0 m;
total width – 15.41 m;
carriageway width – 13.25 m.

ARCHWAY PEDESTRIAN CROSSING
Located within Ostashkovskaya Street #30.the arch has U-shape;
total length – 36.0 m;
material – RC;
total width – 3.0 m;
staircase width – 3.35 m;
glazing – solid polycarbonate.
